HP ProCurve J4904A

HP ProCurve J4904A

TeamKCI has extensive hands on experience with the HP ProCurve J4904A switch and continues to maintain and repair them. Parts and replacement units are in stock and can ship overnight.

The HP ProCurve J4904A reached it’s end of support
on December 30, 2014

[circular_countdown settings_id=’4′]

TeamKCI will continue to support these units for as long as you use them.

Request A Quote

Overview

Let TeamKCI help you design the most cost-effective Storage Area Network Solution.

Used & Refurbished HP Options TeamKCI sells both new and refurbished equipment.  Used HP systems are available at big savings offering our customers alternative financial options to maximize their IT dollars.

Warranty & Support TeamKCI offers a 12 month warranty and 9-5 technical support on all refurbished HP ProCurve J4904A switches and all other pre-owned refurbished HP SAN equipment we sell.  Extended warranties and 24x7x4 onsite support are also available for an additional charge.  Learn more.

How to Get Started? For more information on a HP ProCurve J4904A switch or any other HP product simply complete the TeamKCI Quick Quote form on this page or call TeamKCI at 201-934-6500 Ext. 11 for immediate assistance.

TechSpecs

Technical Specifications

Connectivity
Routing/switching capacity
96 Gbps
Networking
Address table size
16,000 entries
Management features
ProCurve Manager (included); ProCurve Manager Plus; command line interface; Web browser; configuration menu; out-of-band management (serial RS-232C)
Latency
<5.4 µs (FIFO 64-byte packets)
Memory and processor
Processor type and speed: Motorola Power PC MPC8245, 266 MHz; Flash capacity: 8 MB; SDRAM: 64 MB
Performance
Throughput
up to 69.3 million pps (64-byte packets)
Ports
External I/O ports
44 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T) Media Type: Auto-MDIX Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only; 1 RS-232C DB-9 console port; 4 dual-personality ports – each port can be used as either an RJ-45 10/100/1000 port or an open mini-GBIC slot (for use with mini-GBIC transceivers)
Power
Power availability
1.0/0.5 A
Power consumption
83 W
Power requirements
100–127 VAC/200–240 VAC; 50/60 Hz
Rack
Rack mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only.
Operating temperature range 0° to 55°C
Heat dissipation 283 BTU/hr
Acoustic pressure emissions <53 dB; DIN 45635T.19 per ISO 7779
Operating altitude 4,600 m
Electromagnetic compatibility FCC Class A; EN 55022/CISPR 22 Class A; VCCI Class A
Safety cUL (CSA 950); EN 60950/IEC 60950; NOM-019-SCFI-1994; UL 1950 3rd edition
Compliance industry standards EN: EN55024, CISPR 24; ESD: IEC 61000-4-2; 4 kV CD, 8 kV AD; Radiated: IEC 61000-4-3; 3V/m; EFT/Burst: IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line); Surge: IEC 61000-4-5; 1 kV/2 kV AC; Conducted: IEC 61000-4-6; 3V; Power frequency magnetic field: IEC 61000-4-8; 1A/m, 50 or 60 Hz; Voltage dips and interruptions: IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25 periods; Harmonics: EN61000-3-2, IEC61000-3-2; Flicker: EN61000-3-3, IEC61000-3-3
Product weight 4.88 kg
Product dimensions (W x D x H) 43.99 x 42.93 x 4.45 cm
